One-way device:
1. Embedded with super hard alloy and matched with precision rollers, it has wear resistance, stability, high precision and long life.
2. The gears are HRC60 heat treated. Re-precision grinding, high transmission precision.
Roller: It adopts hollow type, light weight and small rotational inertia, which can be stopped in time to ensure the feeding accuracy. After heat treatment HRC60. Hard chrome plating and regrinding, high hardness, excellent wear resistance and long life.
Disc brake (general brake device): The clutch is used to make the two sides of the disc contact, with long life, good stability and high precision.
Reverse device:
1. The structure is the same as that of the one-way device, which can accurately control the lower wheel, and the lower wheel will not have the slightest backward phenomenon after long-term use, with high stability and precision.
2. It is not because of the residual oil splashed during stamping, the brake failure will cause the next wheel to reverse and the feeding distance to be inaccurate.
3. It is not easy to generate high heat.
4, with super hard alloy and rollers, not easy to wear.
5. The action mode is that the rollers make circular motion, so there will be no seizure phenomenon.
6. The friction force is small, the required rotational torque is relatively reduced, and the transmission mechanism is less likely to be damaged.
7. If the reverse device is equipped, the speed can reach 30 m/min, generally 20 m/min, which increases the efficiency by 50%.
8. The special structure increases the service life.
